- Single-phase Input/Output
- Line-interactive technology
- Compact size, light weight
- Equipped with AVR circuit
- Microprozessor control
- Pseudo-sinusoidal output
- Fast battery charger
- Designed for any application kind
- Wide input voltage range
- Output voltage regulation
- Frequency auto detection
- DC Start function
- Efficiency superior than 98% (energy saving)
- Low audible noise level Smart RS-232 communication port
- Modem/Phone line surge protection
- Shutdown software for most common Operating Systems
| Model | Compact 600 | Compact 900 |
| Nominal Capacity [VA] | 400 | 600 |
| Input | ||
| Nominal Voltage | 115V / 230V | |
| Voltage range | 80-145 V / 160-290V | |
| Frequency | 47/63 Hz auto detection | |
| Output | ||
| Outlets (IEC 320) | 3 | |
| Power rating VA(Watt) | 400 (240) | 600 (360) |
| Nominal Voltage | 115 V / 230 V | |
| Voltage in battery mode | 230V± 10% | |
| Wave form | Pseudo-sinusoidal | |
| Frequency in battery mode | 50/60 Hz auto ranging ± | |
| System | ||
| Transfer time | 3ms | |
| AC-AC Efficiency | 98% | |
| Battery, autonomy | Sealed lead acid maintenances free, 10 min at half load | |
| Communication port | Smart RS 232 | |
| Protections | Deep battery discharge, over-current, short circuit, temperature | |
| Acoustic noise | < 30 dBA | |
| Operating temperature | 0-40° C | |
| Humidity max | 0-90% non condensing | |
| In compliance with | Safety EN 50091-1-1; EMC EN 55091-2 cl.B | |
| Data line protection | RJ45 (telephone) filtering socket | |
| Physical | ||
| Dimensions WxDxH mm | 100x330x140 | |
| Weight Kg | 5 | 5 |
